Conductivity OEM™ Circuit

#EC-OEM
Patent Protected

You may also like…

$9.99 USD

@ QTY 2,000
Add & Save

QTY 1

$67.99

QTY 10

$59.99

QTY 25

$55.99

QTY 50

$47.99

QTY 75

$44.99

QTY 100

$35.99

QTY 500

$29.99

QTY 1,000

$19.99

QTY 2,000

$9.99

Designed for mass production, the OEM-EC Circuit lets engineers add laboratory-grade conductivity measurements to any product. Because it can work with any off the shelf conductivity probe, you have the freedom to design a system that meets the needs of your customers without having to use expensive probes or connectors.

ReadsConductivity
Total dissolved solids (ppm)
Salinity = PSU (ppt) 0.00 − 42.00
Range 0.07 − 500,000+ μS/cm
Accuracy+/ – 2%
Response time 1 reading every 640ms
Supported probes K 0.01 – K 600 any brand
Calibration1 or 2 point
Temp compensation Yes
Data protocol SMBus/I2C
Default I2C address 0x64
Operating voltage 3.0V − 5.5V
Data format ASCII
Dimensions:12mm x 11mm (0.47″ x 0.43″)
Weight:0.53 grams

Designed for mass production, the OEM-EC Circuit lets engineers add laboratory-grade conductivity measurements to any product. Because it can work with any off the shelf conductivity probe, you have the freedom to design a system that meets the needs of your customers without having to use expensive probes or connectors.

ReadsConductivity
Total dissolved solids (ppm)
Salinity = PSU (ppt) 0.00 − 42.00
Range 0.07 − 500,000+ μS/cm
Accuracy+/ – 2%
Response time 1 reading every 640ms
Supported probes K 0.01 – K 600 any brand
Calibration1 or 2 point
Temp compensation Yes
Data protocol SMBus/I2C
Default I2C address 0x64
Operating voltage 3.0V − 5.5V
Data format ASCII
Dimensions:12mm x 11mm (0.47″ x 0.43″)
Weight:0.53 grams
