RTD 2-Wire Temperature OEM™ Circuit

#RTD-2-OEM

You may also like…

$10.99 USD

@ QTY 1,000+
Add & Save

QTY 1

$32.00

QTY 10

$30.40

QTY 25

$28.80

QTY 50

$25.60

QTY 75

$22.00

QTY 150

$19.00

QTY 250

$17.00

QTY 500

$15.50

QTY 1,000

$10.99

RTD 4-Wire Temperature OEM™ Circuit

For those engineers tasked with mass-producing a device that needs accurate temperature sensing capabilities, the OEM-RTD is a quick and easy solution to a complex problem. This small 12×11 mm SMD component gives you the ability to accurately read from any class of 2 wire platinum RTD probes and has a sensing range of -126.000 °C to +1,254 °C.

RTDResistance Temperature Detector RTD
ReadsTemperature in °C
Range-126.000 °C − 1254 °C
Resolution0.001
Accuracy+/– (0.1 + 0.0017 x ̊C)
Response time1 reading every 420ms
Supported probesAny type & brand PT-100 or PT-1000 RTD
Supported configuration2 wire RTD
CalibrationSingle point
Data protocolSMBus/I2C
Default I2C address0x68
Operating voltage3.3V − 5.5V
Data formatASCII
Electrical Isolation not needed
Circuit dimensions12mm x 11mm (0.47″ x 0.43″)
Weight0.51 grams

For those engineers tasked with mass-producing a device that needs accurate temperature sensing capabilities, the OEM-RTD is a quick and easy solution to a complex problem. This small 12×11 mm SMD component gives you the ability to accurately read from any class of 2 wire platinum RTD probes and has a sensing range of -126.000 °C to +1,254 °C.

RTDResistance Temperature Detector RTD
ReadsTemperature in °C
Range-126.000 °C − 1254 °C
Resolution0.001
Accuracy+/– (0.1 + 0.0017 x ̊C)
Response time1 reading every 420ms
Supported probesAny type & brand PT-100 or PT-1000 RTD
Supported configuration2 wire RTD
CalibrationSingle point
Data protocolSMBus/I2C
Default I2C address0x68
Operating voltage3.3V − 5.5V
Data formatASCII
Electrical Isolation not needed
Circuit dimensions12mm x 11mm (0.47″ x 0.43″)
Weight0.51 grams
