EZO™ pH Circuit
#EZO-pH
Patent Protected
You may also like…
Add & Save
4+ Units | $38.00 |
10+ Units | $37.00 |
25+ Units | $36.00 |
Although it is a common measurement, accurately reading pH is very difficult. Atlas Scientific’s EZO-pH circuit gives engineers the ability to read pH with the same accuracy and capabilities that were traditionally only found in expensive bench-top meters.
With an easy to use data protocol, simple command structure, and an easy to read datasheet engineers of any skill level will be able to add high accuracy pH readings to their next project quickly.
| Reads | pH |
| Range | .001 − 14.000 |
| Resolution | .001 |
| Accuracy | +/– 0.002 |
| Response time | 1 reading per sec |
| Supported probes | Any type & brand |
| Calibration | 1, 2, 3 point |
| Temp. compensation | Yes |
| Data protocol | UART & I2C |
| Default I2C address | 99 (0x63) |
| Operating voltage | 3.3V − 5V |
| Data format | ASCII |
| Circuit dimensions | 13.97mm x 20.16mm (0.55″ x 0.79″) |
| Weight: | 1.76 grams |
-
EZO™ pH Circuit Datasheet -
Wiring Diagram -
Arduino Uno Sample Code - Arduino Mega Sample Code
- Arduino I2C Sample Code
-
Raspberry Pi Sample Code (UART, I2C, USB) -
DIY pH Dosing Pump - pH and Salinity Monitoring System with LEDs
- UART and I2C mode switching
-
EZO UART Library - EZO I2C Library
-
CE Certificate - RoHS Certificate
-
EZO™ pH Circuit Footprint File (*.dxf) - EZO™ pH Circuit 3D model (*step)
