RTD 4-Wire Temperature OEM™ Circuit
You may also like…
QTY 1 |
$35.00 |
QTY 10 |
$31.70 |
QTY 25 |
$28.40 |
QTY 50 |
$23.45 |
QTY 75 |
$19.29 |
For those engineers tasked with mass-producing a device that needs accurate temperature sensing capabilities, the OEM-RTD is a quick and easy solution to a complex problem. This small 11×13 mm SMD component gives you the ability to accurately read from any class of 2, 3, or 4 wire platinum RTD probes and has a sensing range of -126.000 °C to +1,254 °C.
RTD Resistance Temperature Detector
RTD
Reads
Temperature in °C
Range
-126.000 °C − 1254 °C
Resolution
0.001
Accuracy
+/– (0.1 + 0.0017 x ̊C)
Response time
1 reading every 420ms
Supported probes
Any type & brand PT-100
or PT-1000 RTD
Supported configuration
2 wire, 3 wire or 4 wire RTD
Calibration
Single point
Data protocol
SMBus/I2C
Default I2C address
0x68
Operating voltage
3.0V − 3.6V Data format ASCII
Electrical Isolation not needed
Circuit dimensions
11.1mm x 13.3mm (0.43″ x 0.52″)
Weight 0.56 grams
